Research photos

Photo Number Light Source     Light to Target Distance Obstruction details and other important notes
ap-01.JPG Green Laser 3.0 Meters None – Control image
ap-02.JPG Green Laser 3.0 Meters Single Slit
ap-03.JPG Green Laser 3.0 Meters Single Slit, 1/3 beam blocked
ap-04.JPG Green Laser 3.0 Meters Single Slit, 2/3 beam blocked
ap-05a.JPG Green Laser 3.0 Meters Offset 2 cm
ap-05b.JPG Green Laser 3.0 Meters Offset 1.5 cm
ap-06.JPG Green Laser 3.0 Meters Offset 1 cm
ap-07a.JPG Green Laser 3.0 Meters Offset 5 mm
ap-07b.JPG Green Laser 3.0 Meters Offset 5 mm, dark background
ap-08.JPG Green Laser 3.0 Meters Offset 1 mm
ap-09.JPG Red Laser 3.0 Meters None – Control Image
ap-10.JPG Red Laser 3.0 Meters 1.0 mm slit
ap-11.JPG Red Laser 3.0 Meters 0.5 mm slit
ap-12.JPG Red Laser 3.0 Meters 0.1 mm slit
ap-13.JPG Green Laser 3.0 Meters offset obstruction w/vertical polarization
ap-14.JPG Green Laser 3.0 Meters offset obstruction w/45 degree polarization
ap-15.JPG Green Laser 3.0 Meters offset obstruction w/horizontal polarization
ap-16.JPG Green Laser 3.0 Meters Single – Left Obstruction
ap-17.JPG Green Laser 3.0 Meters Single Left Obstruction then 0.3 mm Wire
ap-18.JPG Green Laser 3.0 Meters 0.3 mm Wire then Single Left Obstruction
ap-19.JPG Green Laser 5.0 Meters pair of .1 mm slits seperated by .3 mm post
ap-20.JPG Red Laser 5.0 Meters pair of .1 mm slits seperated by .3 mm post
